Smappee Infinity - Connection diagram - 1 P (1*230 V)

Smappee Infinity – Installation manual – English
14
Connection diagram – 1P (1*230V)
WARNING: The above wiring and colour scheme is indicative. National regulations
must be respected. Wiring for Europe must be at least 1mm2 / 600 V and protected by
a 6A circuit breaker.
Brown – L1
Blue – Neutral
