Smappee Infinity – Installation manual – English
Step 1: Physical installation
• Remove the green connector from the Input module.
• Connect the two pulse wires of the appliance you want to monitor to a pulse input of the
green connector by mounting wires
*
using the removable push in spring connection.
• Place the green connector back in the module.
• Connect the Input module between the Power Box, Genius or other modules via the B-bus
using both B ports. Use the supplied Smappee Bus cable or a custom twisted-pair RJ10 cable.
*
Use a solid cable with diameter range 0.5 to 1.5 mm² (20 AWG - 15 AWG) to connect the
pulse output with the green connector. Stranded cable is not recommended. Strip the
wire for 5 mm.
Removable push in spring connection:
• Press the orange push button above each wire input using a small flat screwdriver.
Keep the button pressed when inserting the wire. Release the orange push button
to hold the wire in place.
• Make sure the wire is connected correctly. Pull gently on the wire and check
whether it’s connected firmly.
You can use a custom RJ10 cable instead of the standard Smappee Bus cable. The RJ10
must be a twisted pair cable. Pins 1 & 4 and Pins 2 & 3 must be twisted pairs. See the
Smappee Bus cable specification in section 13 of the Infinity Installation manual.
Both ports (RJ10 connectors) of the modules are identical. There’s no special attention
needed for making the interconnections.
Make sure the wire connection of the green connector is connected correctly. Pull gently
on the wire and check whether it’s connected firmly.
Step 2: Configuration
The Input module can be configured when the Smappee Infinity is installed and operational. The
inputs of the module have to be configured individually.
Configure the Input module using the Smappee App: Go to Settings – Your Smappee
monitors – Infinity modules – Select Input module. Follow the procedure in the app to
complete the configuration of each input.
If a physically installed Input module is not shown in the Infinity modules list in the
Smappee App, tap Scan for modules at the bottom of the Infinity modules screen.
Consult the data of the inputs in the Smappee App and Dashboard:
• App: Open the App and scroll down on the dashboard screen to Live inputs. Tap a
specific input to view its historical data.
• Dashboard: Open the Dashboard and add a Live inputs card.
