2 Mounting Instructions
4 – Tighten the hex screw that join the two
parts of the magnet bracket. It will avoid
sliding of the two parts of the bracket during
the fastening of the stem nuts.
5 – Tighten the stem nuts.
6 – Attach the “clamps” to the positioner
bracket.
If your actuator is pillar type, go to step 15
to see the instructions.
