Owner’s Manual
Specifications
_________________________________________________________________________________________________
ST-GP9500
ST-GP9500/ST-GP9500E/ST-GP9500EB
Engine Type 4-Stroke OHV Air Cooled Single Cylinder EPA and CARB Certified
Horsepower 15
Engine Displacement (cc) 420cc
Running Watts 7500w
Starting Watts 9500w
Rated Frequency 60HZ
Rated Voltage 120V/240V
Rated Current 62.5A
Run Time 10hrs at 50% load
Receptacles (qty.) (4) 120V AC; (1) 240V/120 AC; (1) 120V 30A AC; (1) 12V 10A DC
Net/Gross Weight 185/187lbs.
Noise Level (dB) 73dB
Fuel Type Unleaded gasoline
Fuel Capacity (gal.) 7
Oil Level Meter Yes
Oil Type SAE 10W-30
Start Type Recoil (Electric on E and EB models)
AC Volt Meter Yes
Frame Construction Tubular Steel
Wheel & Handle Kit 10" No-flat Tires; Duel handles; 3 1/2" crutches
Dimensions L x W x H (in.) 27" x 24" x 27"
Battery (optional) 12 Volt 17 Amp Hours Nut & Bolt Terminals
