HGM400 Series Genset Controller User Manual
HGM400 Series Genset Controller ISSUE 2015-05-27 Version 1.6 Page 24 of 44
No
Items
Range
Default
Description
12
Safety On Delay
(1-60)s
10
Alarms for low oil pressure, high
temperature, under speed, under
frequency/voltage, charge alt
failure are inactive.
13
Start Idle Time
(0-3600)s
0
Idle running time of genset when
starting.
14
Warming Up Time
(0-3600)s
10
Warming time between genset
switch on and high speed
running.
15
Cooling Time
(3-3600)s
10
Radiating time before genset
stop, after it unloads.
16
Stop Idle
(0-3600)s
0
Idle running time when genset
stop.
17
ETS Solenoid
Hold
(0-120)s
20
Stop electromagnet’s power on
time when genset is stopping.
18
Fail to Stop Delay
(0-120)s
0
Time between ending of genset
idle delay and stopped when
“ETS time” is set as 0;
Time between ending of ETS
hold delay and stopped when
“ETS time” is not 0.
19
Breaker Close
Time
(0-10)s
5.0
Pulse width of mains/generator
switch on. When it is 0, means
output constantly.
20
Flywheel Teeth
(10-300)
118
Tooth number of the engine, for
judging of starter crank
disconnect conditions and
inspecting of engine speed. See
the installation instructions.
21
Gen Abnormal
Delay
(0-20.0)s
10.0
The alarm delay of generator
over voltage and under voltage.
22
Gen Over Voltage
(30-620)V
264
When generator voltage has
exceeded the set value and the
“Gen abnormal delay” has
expired, Gen Over Voltage is
active. When set the value as
620V, the controller does not
detect over voltage signal.
