HGM6100N Series Genset Controller User Manual Page 13 of 47
No.
Items
Description
between B+ and the charger D+ (WL) is above the Failed to Charge
voltage difference for 5s, the controller shall issue “Failed to Charge”
warning, while at the same time LCD displays “Failed to Charge” warning.
6
Battery Under Voltage
When the battery voltage of genset is lower than threshold, controller will
send warning alarm signal and it will be displayed in LCD.
7
Battery Over Voltage
When the battery voltage of genset is higher than threshold, controller will
send warning alarm signal and it will be displayed in LCD.
8
Low Coolant Level
When low coolant level input is active, controller will send warning alarm
signal and it will be displayed in LCD.
9
Temp. Sensor Open
When sensor hasn’t connected to corresponding port, controller will send
warning alarm signal and it will be displayed in LCD.
10
Oil Pressure Sensor
Open
When sensor hasn’t connected to corresponding port, controller will send
warning alarm signal and it will be displayed in LCD.
11
Maintenance Due
Warning
Maintenance type is running time. When genset running time is longer
than maintenance time of user setting, or the maintenance type is date,
the current date is over the setting date and the maintenance action is
set as warning, controller sends warning alarm signal and it will be
displayed in LCD.
12
High Temp.
When the water/cylinder temperature of genset is higher than threshold
and Enabled High Temp. Stop Inhibit or Input High Temp. Stop Inhibit is
active, controller will send warning alarm signal and it will be displayed in
LCD.
13
Low Oil Pressure
When the oil pressure of genset is less than threshold and Enabled Low
Oil Pressure Stop Inhibit or Input Low Oil Pressure Stop Inhibit is active,
controller will send warning alarm signal and it will be displayed in LCD.
14
Input Warn
When external input is active, controller will send warning alarm signal
and it will be displayed in LCD.
15
Failed to Charge
When “Failed to Charge” input is active, controller will send warning alarm
signal and it will be displayed in LCD.
16
Over Power
If over power detection is enabled, when the controller detects that the
power value (power is positive) has exceeded the pre-set value and the
action selects “Warn”, it will initiate a warning alarm.
17
ECU Warn
If an error message is received from ECU via J1939, it will initiate a
warning alarm.
