HGM6100N Series Genset Controller User Manual Page 40 of 47
13.3 CUMMINS QSM11 (IMPORT)
It is suitable for CM570 engine control module. Engine type is QSM11 G1, QSM11 G2.
Table 17 – C1 Connector
Terminals of controller
C1 connector
Remark
Configurable output1
5&8
Set configurable output 1 as “Fuel Relay
Output”. Outside expand relay, when fuel
output, making make port 5 and port 8 of
C1 be connected.
Starting relay output
-
Connect to starter coil directly.
Table 18 – 3 Pins Data Link Connector
Terminals of controller
3 pins data link connector
Remark
CAN_SCR
C
CAN communication shielding line
(connect to ECU terminal only).
CAN(H)
A
Using impedance 120Ω connecting line.
CAN(L)
B
Using impedance 120Ω connecting line.
Engine type: Cummins ISB.
13.4 CUMMINS QSX15-CM570
It is suitable for CM570 engine control module. Engine type is QSX15.
Table 19 – 50 Pins Connector
Terminals of controller
50 pins connector
Remark
Configurable output1
38
Oil spout switch; Set configurable output 1
as “Fuel Relay Output”.
Starting relay output
-
Connect to starter coil directly.
Table 20 – 9 Pins Connector
Terminals of controller
9 pins connector
Remark
CAN_SCR
SAE J1939 shield-E
CAN communication shielding line
(connect to ECU terminal only).
CAN(H)
SAE J1939 signal-C
Using impedance 120Ω connecting line.
CAN(L)
SAE J1939 return-D
Using impedance 120Ω connecting line.
Engine type: Cummins QSX15-CM570.
13.5 CUMMINS GCS-MODBUS
It is suitable for GCS engine control module. Use RS485-MODBUS to read information of engine.
Engine types are QSX15, QST30, QSK23 / 45/60/78 and so on.
