HGM6100N Series Genset Controller User Manual Page 25 of 47
NOTE5: Between input correct password and LCD back light haven’t got dark, input parameter numbers can enter
parameter setting interface when enters “Password Input” again.
NOTE6: In teeth configuration interface, if being in teeth configuration status and frequency is larger than 20Hz,
press start key for auto calculating teeth numbers and press confirm key for changing teeth numbers.
7.2 DEFINED CONTENTS OF PROGRAMMABLE OUTPUT 1-4
Table 8 – Defined Content of Programmable Output 1-4
No.
Items
Description
0
Not Used
Output is disabled when this item is selected.
1
Common Alarm
Including all shutdown alarm and warning alarm. When warning
alarm occurs, the alarm won’t self-lock; When a shutdown alarm
occurs, the alarm will self-lock until alarm is reset.
2
Energize to Stop
Used for the genset with stop solenoid. Pick-up when idle speed is
over while disconnect when ETS delay is over.
3
Idle Control
Used for the genset with idle speed. Pick-up when crank while
disconnect when enter into warming up. Pick-up when stop idle
while disconnect when genset stop completely.
4
Preheat Control
Close before started and disconnect before powered on.
5
Close Gen Output
When close time is set as 0, it is continuous closing.
6
Close Mains Output
HGM6110 without.
7
Open Breaker
When close time is set as 0, Open Breaker is disabled.
8
Speed Raise Relay
Pick-up when enter into warming up time. Disconnect when raise
speed auxiliary input active.
9
Speed Drop Relay
Pick-up when enter into stop idle or ETS solenoid stop (shutdown
alarm). Disconnect when droop speed auxiliary input active.
10
Run Output
Output when genset is in normal running, disconnect when
rotating speed is lower than engine speed after fired.
11
Fuel Pump Control
Pick-up when the fuel level lower than the open threshold or low
fuel level warning is active; disconnect when the fuel level over the
close threshold and the low fuel level warning input is disabled.
12
High Speed Control
Output when it enters into warming up time, and disconnect after
cooling.
13
Auto Mode
The controller is in Auto Mode.
14
Shutdown Alarm
Output when shutdown alarm occurs.
15
Audible Alarm
When shutdown alarm and warn alarm occur, audible alarm is set
as 300s. In audible alarm output duration, when panel any key or
“alarm mute” input is active, it can remove the alarm.
16
Heater Control
It is controlled by cooler of temperature sensor’s limited threshold.
17
Fuel Output
Action when genset is starting and disconnect when stop is
completed.
18
Start Output
Genset output in start output status and open in other status.
19
ECU Stop
Used for ECU engine and control its stop.
20
ECU Power
Used for ECU engine and control its power.
