Smartgen HGM6120CAN - Detroit Diesel DDEC III;IV; Deutz EMR2; John Deere

HGM6100N Series Genset Controller User Manual Page 42 of 47
Terminals of controller
OEM connector of engine
Remark
expansion relay.
CAN_SCR
-
CAN communication shielding line.
CAN(H)
1
Using impedance 120Ω connecting line.
CAN(L)
21
Using impedance 120Ω connecting line.
Engine type: Common J1939.
13.8 DETROIT DIESEL DDEC III/IV
Table 25 – Engine CAN Connector
Terminals of controller
CAN port of engine
Remark
Configurable output 1
Expand 30A relay, battery
voltage is supplied by
relay.
Set configurable output 1 as “Fuel Relay
Output”.
Starting relay output
-
Connect to starter coil directly.
CAN GND
-
CAN communication shielding line.
CAN(H)
CAN(H)
Using impedance 120Ω connecting line.
CAN(L)
CAN(L)
Using impedance 120Ω connecting line.
Engine type: Common J1939.
13.9 DEUTZ EMR2
Table 26 – F Connector
Terminals of controller
F connector
Remark
Configurable output 1
Expand 30A relay, battery
voltage of 14 is supplied
by relay. Fuse is 16A.
Set configurable output 1 as “Fuel Relay
Output”.
Starting relay output
-
Connect to starter coil directly.
-
1
Connect to battery negative pole.
CAN_SCR
-
CAN communication shielding line.
CAN(H)
12
Using impedance 120Ω connecting line.
CAN(L)
13
Using impedance 120Ω connecting line.
Engine type: VolvoEDC4.
13.10 JOHN DEERE
Table 27 – 21 Pins Connector
Terminals of controller
21 pins connector
Remark
Configurable output 1
G, J
Set configurable output 1 as “Fuel Relay
Output”.
Starting relay output
D
CAN GND
-
CAN communication shielding line.
CAN(H)
V
Using impedance 120Ω connecting line.
CAN(L)
U
Using impedance 120Ω connecting line.
