Smartgen HGM6120CAN - Specification

HGM6100N Series Genset Controller User Manual Page 8 of 47
3 SPECIFICATION
Table 2 – Technical Parameters
Items
Contents
Working Voltage
DC8.0V to DC35.0V, continuous
Power Consumption
<3W (Standby mode: ≤2W)
AC System
3P4W
3P3W
1P2W
2P3W
AC15V - AC360V (ph-N)
AC30V - AC620V (ph-ph)
AC15V - AC360V (ph-N)
AC15V - AC360V (ph-N)
AC Alternator Frequency
50Hz/60Hz
Speed Sensor Voltage
1.0V to 24V (RMS)
Speed Sensor Frequency
10,000 Hz (max.)
Start Relay Output
16A DC28V at supply voltage
Fuel Relay Output
16A DC28V at supply voltage
Auxiliary Relay Output 1
7A DC28V at supply voltage
Auxiliary Relay Output 2
7A AC250V volt-free output
Auxiliary Relay Output 3
16A AC250V volt-free output
Auxiliary Relay Output 4
16A AC250V volt-free output
Overall Dimensions
209mm x 166mm x 45mm
Panel Cutout
186mm x 141mm
C.T. Secondary Current
5A (rated)
Working Condition
Temperature: (-25~+70)ºC; Relative Humidity: (20~93)%RH
Storage Condition
Temperature: (-30~+80)ºC
Protection Level
IP65: when water-proof gasket installed between control panel and
enclosure.
Insulation Intensity
Apply AC2.2kV voltage between high voltage terminal and low
voltage terminal. The leakage current is not more than 3mA within
1min.
Weight
0.56kg
