HGM6100N Series Genset Controller User Manual Page 31 of 47
configuration, multi delays, etc.) otherwise shutdown alarm or other abnormal conditions may
appear.
3) The over-voltage threshold must be greater than the under-voltage threshold; otherwise
over-voltage and under-voltage will occur at the same time.
4) The over-speed threshold must be greater than under-speed threshold, otherwise over speed and
under speed will occur at the same time.
5) Set frequency value (after crank disconnect) as low as possible, in order to disconnect starter
quickly.
6) Programmable input 1-5 cannot be set as the same items, otherwise it cannot realize correct
function; programmable output 1-4 can be set as the same item.
7) If need to shut down after cooling, please set any input as “stop after cooling”, then connect this
input to ground; or set high temperature stop action as “cooling stop”.
— Information
1) LCD will display some information of controller, such as software version, issue date.
NOTE: Pressing will display the status of digital inputs and outputs.
2) Language
User may select display language as Chinese, English, Spanish, Russian, Portuguese, Turkey,
Polish and French.
3) LCD contrast ratio adjustment
Press and (or and ) and adjust LCD contrast ratio, which shall make the LCD
characters clearer. Adjustment range is 0-9.
