Smartgen HGM6510 User Manual

HGM6510 GENSET PARALLEL UNIT
HGM6510 Genset Parallel Unit
ISSUE 2013-07-15
Version 1.7
Page 43 of 52
Pin
Function
Cable
Size
Description
6
Aux. Output 1
2.5mm
2
B+ output，rated 16A
7
Aux. Output 2
2.5mm
2
B+ output，rated 16A
8
Aux. Output 3
2.5mm
2
B+ output，rated 16A
9
Charger(D+)
1.0mm
2
Connected with charger starter’s D+
terminal. Ground connected is not allowed.
10
Aux. Input 1
1.0mm
2
Digital input
11
Aux. Input 2
1.0mm
2
Digital input
12
Aux. Input 3
1.0mm
2
Digital input
13
Aux. Input 4
1.0mm
2
Digital input
14
Aux. Input 5
1.0mm
2
Digital input
15
Aux. Input 6
1.0mm
2
Digital input
16
Aux. Input 7
1.0mm
2
Digital input
17
Aux. Input 8
1.0mm
2
Digital input
18
Aux. Input 9
1.0mm
2
Digital input
19
Common GND(B-)
1.0mm
2
Connected with enclosure or negative of
starter battery.
20
Magnetic Pickup
1.0mm
2
Connect to speed sensor
21
Magnetic Pickup +
1.0mm
2
22
Magnetic Pickup -
1.0mm
2
23
CAN J1939 SCR
0.5mm
2
Impedance-120Ω shielding wire is
recommended.
24
CAN J1939 (H)
0.5mm
2
25
CAN J1939 (L)
0.5mm
2
26
MSC SCR
0.5mm
2
Use 120Ω shielding wire to connect all
parallel HGM6510 controllers together.
27
MSC (H)
0.5mm
2
28
MSC (L)
0.5mm
2
29
GOV Wire B (+)
1.0mm
2
2-core shielded wire is recommended,
shielding layer connected to the ground at
GOV end.
30
GOV Wire A (-)
1.0mm
2
31
Not Used
32
AVR Wire B (+)
1.0mm
2
2-core shielded wire is recommended,
shielding layer connected to the ground at
AVR end.
33
AVR Wire A (-)
1.0mm
2
34
RS485 SCR
0.5mm
2
PC programming or monitoring port
(Opto-isolation); its single-end earthed.
35
RS485 A (-)
0.5mm
2
36
RS485 B (+)
0.5mm
2
37
38
39
Aux. Output 5
2.5mm
2
Normally open/close volts free contactor.
Rated 16A.
40
Aux. Output 4
2.5mm
2
Normally open volts free contactor. Rated
16A.
41
42
Bus A Phase Voltage
Sensing Input
1.0mm
2
Connected to A-phase of bus (2A fuse is
recommended)
43
Bus B Phase Voltage
Sensing Input
1.0mm
2
Connected to B-phase of bus (2A fuse is
recommended)
