DESCRIPTION OF DISPLAY SYMBOLS
Symbol Meaning
SYS
DIA
PULSE
Systolic Blood Pressure—The ‘top’ blood pressure result
Diastolic Blood Pressure—The ‘bottom’ blood pressure result
Pulse Rate—Pulse rate per minute during the measurement
Millimeters of Mercury—Unit of blood pressure measurement
for this device
Low Battery—Battery life indicator
Pulse Reading—Appears when pulse reading is displayed.
Irregular Heartbeat Symbol—An irregular heartbeat was
detected during the measurement
Average—The display shows the average of the last
three measurements in memory
User / Memory Bank —Indicates which memory bank is in
use for reading storage and memory recall review
AVG
(
( )
)
