SMC Networks EtherNet/IP JXC91 Series User Manual

Electric actuators
To SI
To ENC
To MOT
To PWR
EtherNet/IP™ direct input type
JXC91
Series LES/LESH
Series LEY(G)
Series LEF
Series LER
Series LEPY/LEPS
System Construction
Actuator cable
LE-CP-
Robotic cable
LE-CP-
-S
Standard cable
PLC
Provided by customer
Power supply for controller
24 V DC
Provided by customer
Power supply plug
(Accessory)
Conversion cable
P5742-69
(0.3 m)
This conversion cable is used
when connecting this controller
to the optional teaching box
[LEC-T1] or the controller set-
ting kit [LEC-W2] offered with
the LEC series.
Series LEL
Series LEH
Series LEM
Teaching box
(With 3 m cable)
LEC-T1-3EG
Or
Option
USB cable
PC
Communication cable
(3 m)
(A-mini B type)
(0.3 m)
Controller setting kit
Controller setting kit
(Communication cable, conversion unit and USB cable are included.)
LEC-W2
Note) The optional conversion cable is required separately.
Option
Page 4
Page 4
1
Series JXC91

SMC Networks EtherNet/IP JXC91 Series Specifications

General

Brand	SMC Networks
Model	EtherNet/IP JXC91 Series
Category	Controller
Language	English
