SMC-EZ1026DT V.2
16
accordingly.
•There are two different mode of VLAN supported in this system – Port
Base VLAN, MTU/MDU. The choice you made here will ultimately decide
the VLAN mode and function for entire system (the configuration of the
other two VLAN mode will have no effect to the system behavior).
B. Port Configuration
Figure 3-9. The Port Configuration Menu
The Ports (24+2) of the system are divided and displayed in three
separated pages. Use PREV PAGE, NEXT PAGE to list desired port
range and select the port.
In the port configuration screen you can configure the common
characteristics such as speed negotiation, and flow control, as well
as the following special features provided with the system:
• Bandwidth provisioning - 8 levels of speed control facilitate the
provisioning control for access provider.
