C
ONFIGURING
THE
S
WITCH
8
Web Configuration
Displaying Status Overview
You can easily identify the system by displaying the device name, location
and contact information.
Field Attributes
System Information
• System Name – Name assigned to the switch system.
• Number of Ports – Number of built-in ports.
• Hardware Version – Hardware version of the main board.
• Code Version – Version number of the code.
• Serial Number – The serial number of the switch.
Broadcast Control Sets the broadcast storm control parameters
for every port on the Switch.
21
Port Mirroring Sets up the port mirroring features of the
switch to enable traffic monitoring.
22
TRUNKS 23
Membership Specifies ports to group into static trunks 24
Settings Configures trunk connection settings 24
Rate Limiting Sets the rate limiting parameters for each
Trunk configured on the Switch.
25
VLANS 26
VLAN Settings Configures the VLANs on the switch for both
Ports and Trunks
26
QOS 29
Settings Sets the priority of packets within the switch. 29
LOGOUT Quits to the Login page.
Table 2-1 Switch Main Menu (Continued)
Menu Description Page
To Next Page
