4.1.4 Connecting water supply
C
Thewatersupplypressurerequiredtoruntheproductisbetween1to10bars(0.1–1MPa).Itisnecessarytohave
10–80litersofwaterflowingfromthefullyopentapinoneminutetohaveyourmachinerunsmoothly.Attachapressure
reducing valve if water pressure is higher.
Ifyouaregoingtousethedoublewater-inletproductasasingle(cold)water-inletunit,youmustinstallthesuppliedstopper
to the hot water valve before operating the product. (Applies for the products supplied with a blind stopper group.)
A
CAUTION: Modelswithasinglewaterinletshouldnotbeconnectedtothehotwatertap.Insuchacasethelaundrywill
get damaged or the product will switch to protection mode and will not operate.
CAUTION: Donotuseoldorusedwaterinlethosesonthenewproduct.Itmaycausestainsonyourlaundry.
Connectthespecialwatersupplyhosessuppliedwiththeproducttothewaterinletsonthe
product.Redhose(left)(max.90ºC)isforhotwaterinlet,bluehose(right)(max.25ºC)is
for cold water inlet.
Makesurethatthehotandcoldwatertapsareconnectedcorrectlywhentheproductis
beinginstalled.Otherwise,yourlaundrywillcomeouthotattheendofthewashingprocess
and wear out.
1 Tightenthenutsofthehosebyhand.Neveruseatoolwhen
tightening the nuts.
2 When hose connection is completed, check whether there is leak
problemsattheconnectionpointsbyopeningthetapsfully.Ifany
leaks occur, turn off the tap and remove the nut. Retighten the nut
carefullyaftercheckingtheseal.Inordertopreventthewaterleaks
andresultantdamages,keepthetapsclosedwhenyoudonotuse
the product.
4.1.5 Connecting the drain hose to the drain
• Attachtheendofthedrainhosedirectlytowastewaterdrain,lavatoryorbathtub.
A
CAUTION: Your drain house will be flooded if the hose comes out of its housing during water discharge. Moreover, there
is risk of scalding due to high washing temperatures! In order to prevent such situations and make sure that the machine
performswaterintakeanddischargeprocesseswithoutanyproblem,fixthedrainhosesecurely.
100cm
40cm
•Connectthedrainhosetoaminimumheightof40cm
and a maximum height of 100 cm.
•Incasethedrainhoseiselevatedafterlayingitonthe
floor level or close to the ground (less than 40 cm above
the ground), water discharge becomes more difficult and
thelaundrymaycomeoutexcessivelywet.Therefore,
follow the heights described in the figure.
• Topreventthewastewatertogobackintothemachineagainandtoensureeasydrainage,donotimmerse
the end of the hose into the waste water or do not insert it into the drain for more than 15 cm. If it is too
long, cut it short.
• Theendofthehoseshouldnotbebent,itshouldnotbesteppedonandthehosemustnotbepinched
between the drain and the machine.
• Ifthelengthofthehoseistooshort,useitbyaddinganoriginalextensionhose.Lengthofthehosemay
not be longer than 3.2 m. To avoid water leak failures, the connection between the extension hose and the
drain hose of the product must be fitted well with an appropriate clamp as not to come off and leak.
