Smith-Root eDNA Sampler - System Specifications; Battery and Runtime Details; Dimensions, Weight, and Physical Specs; Sensor, GPS, and Communication Specs

23
INSTRUCTION MANUAL
2019
SPECIFICATIONS*
Batteries
Main battery:
9.6 Ahr 12.8V LiFePO4
Remote battery:
1900 mAHr 1.2V NiMH
Runtime Main Battery:
6-8 Hrs
Runtime Remote Battery:
~ 4 Hrs
Dimensions and weights
Dimensions w/backpack:
30.5 (775mm) H X 16.4 (416.5mm)W X 15 (381mm)D
Handheld unit dimension:
16 (406.4mm) H X 15 (381.0mm) W X 9.25 (235mm) D
Weight w/o battery:
24.0 lbs. 10.89kg
Handheld unit weight w/o battery and remote:
16.2 lbs. 7.35kg
Main battery weight:
3.0 lbs. 1.36kg
Remote battery weight:
0.1 lbs 45.4g
Telescoping pole dimensions including bipod:
41.5 (1054.1mm) to 144 (3657.6mm) L X 5.25 (133.4mm) D
Telescoping pole weight with bipod:
7 lbs. 3.18kg
Remote control dimensions:
4.7 (119.4mm)L X 2.5 (63.5mm)W X 0.94 (23.9mm)H
Remote weight:
0.4 lbs. 181.5g
Sensor specs
Minimum flow rate:
0.1 l/min
Maximum flow rate:
1.4 l/min
Maximum measurable volume:
999.9 l
Volume accuracy:
> 90% at 0.1 l/min or higher flow
GPS system compatibility:
GNSS (GPS, Galileo, GLONASS, BeiDou)
Number of channels:
72
GPS, GLONASS sensitivity:
-167dBm
GPS position accuracy:
2.5 meter
Communications
USB:
2.0
Log File Format:
.csv
Pump specs
Ports:
1/4 inch ID tubing
Priming vacuum:
~ 5 psi
Maximum wetted vacuum:
14 psi (96.5 kilo-pascals)
*Specifications subject to change without notice.
© 2019, Smith-Root, Inc.
