Smith SPS8 - Page 17

SMITH Manufacturing 1-954-941-9744 www.SmithMfg.com
1/2009
17
DELUXE BUSHED DRUM ASSEMBLY
(P/N: 65050-D)
CF2618™
ILL# P/N Oty. Description
1 65050-D 1 Drum Assembly (includes #2 - #6)
2 65052 1 Kit (Set of 6 Shafts, 12 Bushings)
3 65054A 2 Retaining Plate (incl. #4 - #6)
4 10801 6 Lock Washer, 5/16
5 110053 6 Cap Screw, 5/16 x 18 x 3/4
6 110213 6 Washer, 5/16
7 S-20150.4 6 Cutter Shaft, 1/2”
8 12230 $ Spacer, 1/2”
9 HS1000™ $ Steel Beam Cutter
HS1008™ $ Steel Star Cutter
CF2516™ $ 6 Spike Tungsten Carbide Cutter
CF2535™ $ 5 Edge Carbide Scraping Cutter
CF2616™ $ 6 Spike Tungsten Carbide Cutter (large)*
CF2618™ $ 8 Spike Tungsten Carbide Cutter (large)*
CF2150™ $ 6 Edge Carbide Scraping Cutter (large)*
10 65055 12 Drum Bushing (.75” OD)
11 65049 1 Bushing Removal Punch
$ Refer to cutter set up on pages 14-15
   *Forusewith5”RearWheels(P/N:52002)only.
SPS8
