23
f. Align the oil compartment’s mounting hole with the selector’s and use the mounting connector in the
accessory box 1 of the tap selector to connect these two parts (see Figure-6-9). Torque is 50～60N.m.
It’s dangerous to connect wrongly. After removing the positioning plate, it’s
forbidden to move the genevawheel driving piece
Pay attention to the diverter switch and tap selector’s verticality (the
deviation should be smaller than 2%)
