Introduction Control Buttons
Environmental Conditions:
This product is intended for indoor use only
This product is rated for Pollution Degree 2 (normal conditions)
Power Supply:
Supply Rating; 15 VDC. 2A
2.3 Control Buttons
There are five control buttons located on the right side of the unit near the handgrip:
All other tool operations are controlled through the touch screen.
2.3.1 Accept (Y/a) Button
The Y/a button is used to do the following:
• To select an item that was highlighted using the direction buttons.
• To advance to the next screen in a series.
• To answer Yes when a Yes or No choice is given.
Button Icon Description
Accept, Yes
Selects a menu or program, advances to the
next screen, or provides a yes answer to a
question on the screen.
Directional Arrows
Moves the highlight on the display screen up,
down, left, and right, as indicated by the arrows.
Cancel, No
Exits a menu or program, returns to the
previous screen, or provides a no answer to a
question on the screen.
Shortcut
A function button that can be programmed to
provide a shortcut for performing a variety of
routine tasks.
Power, On/Off
Turns the unit on and off. Also, press and hold
for 5 seconds for emergency shutdown.
