36
Scanner Operations Operations
1— Previous Frame button
2— Next Frame button
3— Play button
4— Position indicator
5— Frame counter (current frame/total frames)
Figure 5-11 Sample paused frame of data
2. Scroll to review the data in the frame.
3. To switch frames, touch Previous Frame or Next Frame. Each button touch moves one
frame in the selected direction.
z To resume collecting data:
• Touch the Record button.
The display changes to live data and the Pause icon is shown on the toolbar. The display also
returns to text mode if that was the mode being used before data collection was paused.
i The Shortcut button can be set to perform the Pause/Play function. See Configure Shortcut Key‚
on page 55, for additional information.
123 4 5
