Snap-On MM250SL User Manual

18 Snap-on Tools Corporation Kenosha, WI 53141-1410
FIGURE D2 - WIRE DRIVE ASSEMBLY (SN-138C24M)
3213
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
1
2
3
4
5
6
8
7
10
9
10A
10B
11
12

Snap-On MM250SL Specifications

General

Welding Amperage Range	30 - 250 A
Wire Feed Speed	50 - 700 IPM
Welding Process	MIG (GMAW)
Input Frequency	60 Hz
Rated Output	250 A at 28 VDC
Spool Size Capacity	4 inch
Input Phase	Single Phase
