Snap-On MM250SL User Manual

8 Snap-on Tools Corporation Kenosha, WI 53141-1410
FIGURE B - LEFT SIDE VIEW & INTERNAL COMPONENTS
1
4
5
6
7
8
9
2627
10
13
14
15
16
18
17
19
20
21
25 24 23 22
3
2
11
12 FIG. B1

Snap-On MM250SL Specifications

General

Welding Amperage Range	30 - 250 A
Wire Feed Speed	50 - 700 IPM
Welding Process	MIG (GMAW)
Input Frequency	60 Hz
Rated Output	250 A at 28 VDC
Spool Size Capacity	4 inch
Input Phase	Single Phase
