Snap-On MM250SL User Manual

6 Snap-on Tools Corporation Kenosha, WI 53141-1410
FIGURE A - FRONT ASSEMBLY
1
2
3
4
5
6
7
8
2122232425
9
10
11
12
13
14
15
16
17
18
19
20

Snap-On MM250SL Specifications

General

Welding Amperage Range	30 - 250 A
Wire Feed Speed	50 - 700 IPM
Welding Process	MIG (GMAW)
Input Frequency	60 Hz
Rated Output	250 A at 28 VDC
Spool Size Capacity	4 inch
Input Phase	Single Phase
