• 150 Amp AC/DC TIG Welder
• TIG weld most metals.
• MMA “Stick Welding” with optional cable
assembly.
• Inverter technology allows the welder to be
lightweight (37lbs.) and still able to perform
most welding applications.
• The adjustable amperage output of a minimum
of 5 amps, along with pulse technology, allows
welding of extremely thin materials.
• The maximum of 150 amps will weld most
applications up to ¼” with multiple passes.
• Power Factor Correction “PFC” system only
requires a 30 amp 220 volt circuit saving
substantial electric cost. This also allows
increased input voltage tolerance of +15% to -
20%.
• High frequency start allows for easy arc
starting and can be turned off for scratch start if
needed.
• Scratch start feature if high frequency start is
not desirable.
• Adjustable upslope and downslope feature
helps to prevent burn through at the edge of
the material.
• Adjustable post gas prevents air from getting
to material before it cools.
• Pulsed arc for working even on thin sheets,
where the heat transferred must be kept to a
minimum.
• Tunnel design construction allowing an
exceptional cooling efficiency, keeping those
components that suffer in dusty environments,
such as electronic circuits, out of the cooling
flow.
• AC balance adjustment or penetration and
tungsten consumption control.
• Adjustable AC Frequency 50 - 150Hz for
precise heat output control.
• Background amperage adjustable from 5 to
150 amps DC and 10 to 150 amps AC.
• Remote foot control can be set for momentary
on or continuous on.
• Optional foot pedal or finger tip torch control
allowing precise amperage adjustment
between low amp and high amp setting.
• The TIG150i includes lightweight torch
assembly, ground cable, flow style regulator,
on/off control switch, installed gas hose, and
consumable tungsten kit. The only additional
start up purchases needed are the input plug
and welding gas.
• Exceptional technical support of over 30 years
of experience by calling 800 ABC WELD.
