Snapmaker Dual Extrusion 3D Printing Module - 2.1.2 A250;A250 T;F250;A350;A350 T;F350

Machine Assembly
18 19
2.1.2 A250/A250T/F250/A350/A350T/F350
01
/04
02
/04
Attach the Dual Extrusion Module to the slider on the X
axis.
Dual Extrusion
Module
×1
M4×8 Screw
×4
Make sure the power switch
is in the Off position.
Attach the two cable clips to the X axis and the Z axis.
Cable Clip
×1
Cable Clip
×1
M4×10 Screw
×1
M4×10 Screw
×1
