Machine Assembly
24 25
Insert the Sliding Nut into the 48CA Beam on the left of the
Enclosure. Adjust the installation position of the Sliding
Nut, in alignment with where the Snap Bushing is.
02
/06
03
/06
Sliding Nut
×1
Attach the new Filament Holder to the Sliding Nut.
M4×10 Screw
×1
