Snapmaker Dual Extrusion 3D Printing Module - Page 14

Machine Assembly
26 27
04
/06
05
/06
Press both sides of the Snap Bushing inside the Enclosure,
and then gently push it out of the Side Panel.
Mount the Filament Tube Holder and the Filament Tube
onto the Side Panel.
Filment Tube Holder
×1
Filment Tube
×2
If you are using the A150 Enclosure, cut the Filament Tube as
needed.
