20
|
Snapmaker Enclosure
|
21
Enclosure Assembly
 13
/28
Connect the Door Switch Cable to either Door Switch Port of the Enclosure Converter.
 14
/28
Connect the LED Strips with the Enclosure Converter using two LED Strip Cables.
LED Strip Cable × 2
