Snapmaker Enclosure
|
29
Enclosure Assembly
21
/28
Align the Side Door with the left side face of the frame, then fix the Side
Door with screws.
22
/28
Connect the Touchscreen to the machine’s Controller and place it on the
Touchscreen Holder of the enclosure.
1:1
M4 × 20 Hex Socket Head
Screw
× 4
Side Door × 1
