D715/snom 715 User Manual Setting up the Phone
Setting up the phone
Delivery Content
en de fr it es
IP Phone snom D715
Quick Start Guide
◦ Base phone unit
◦ Footstand
◦ Handset
◦ Handset cord
◦ Ethernet cable
◦ Quick Start Guide
Attaching and detaching the footstand
The footstand can be attached at two different angles: 28° and 46°.
Note: Before attaching the footstand to the phone, plug the long end of the handset
cord into the connector labelled "
" on the back of the phone and place the cord in the
cable guide.
1. Place the top of the grooves on the footstand (Fig. 1) below the slideguides on the back of the
phone (Fig. 2). For the upright position, the short "legs" of the footstand must be attached to the
phone; for the more horizontal position, use the long ones.
2. Push the footstand upwards onto the slideguides until they lock in place (Fig. 3).
