Snom D7C - D785 Numbering Schemes

22
Snom D7C User Manual Function key numbering system
D785
• SmartLabel keys on phone: fkey idx 0–23, PUI key number 1–24
◦ Page 1: fkey idx 0–5
PUI 1–6
WUI P1–P6
◦ Page 2: fkey idx 6–11
PUI 7–12
WUI P7–P12
◦ Page 3: fkey idx 12–17
PUI 13–18
WUI P13–P18
◦ Page 4: fkey idx 18–23
PUI 19–24
WUI P19–P24
• D7C expansion module 1
Page 1 fkey idx 24–39 PUI 25–40
Page 2 fkey idx 40–55 PUI 41–56
Page 3 fkey idx 56–71 PUI 56–71
• D7C expansion module 2
Page 1 fkey idx 71–87 PUI 72–88
Page 2 fkey idx 88–103 PUI 89–104
Page 3 fkey idx 104–119 PUI 105–120
• D7C expansion module 3
Page 1 fkey idx 120–135 PUI 121–136
Page 2 fkey idx 136–151 PUI 137–152
Page 3 fkey idx 152–167 PUI 153–168
