S2255RT S2755RT - 15286-1 3
Chapter 2 Speci cations
Component Identi cation
Upper Controls
Operator’s
Manual
Platform
Scissor Stack
Rollout Deck
Lower Controls
and Serial Plate
Platform
Entry
Engine
Cabinet
Stabiliser Legs (x4)
Control
Cabinet
Fuel
Cabinet
