Chapter 2 – Specifi cations
S2255RT S2755RT - 15286-1 5
General Specifi cations – S2755RT
SPECIFICATIONS S2755RT
Normal working height Wheels 9.9m 32’ 6”
Stabilisers 10.4m 34’ 1”
Platform fl oor height Wheels 7.9m 25’ 11”
Stabilisers 8.4m 27’ 7”
Rollout deck size 1.2m 47”
Drive speed Below 2.4m 0 to 5.2kph 0 to 3.3mph
Above 2.4m 0 to 0.64kph 0 to 0.4mph
Safe working load
(Rollout deck NOT extended)
Main deck 300kg 750lb
Safe working load
(Rollout deck extended)
Main deck 180kg 396lb
Rollout deck 120kg 265lb
Platform size 2.73 x 1.4m 8’ 11” x 4’ 7”
Stowed height Hand rails up 2.5m 8’ 3”
Hand rails folded down 1.75m 5’ 8”
Overall length 3.3m 11’ 0”
Overall width 1.45m 4’ 9”
Gradeability 35%
Lift time 24 - 29 seconds
Lower time 40 - 42 seconds
Turning radius Inner 2.5m 8.2’
Outer 4.75m 15.6’
Maximum wind speed 12.5m/s 45kph 28mph
Insulation rating Nil
Tyres Poly fi lled loader lug 23” x 8.9” x 12”
Overall weight 2750kg 6063lb
Ground clearance Minimum 170mm 7”
Mid cabinet 260mm 10.2”
Maximum sound level at platform 86db
Maximum outrigger load 1470kg 3240lb
Maximum wheel load 1470kg 3240lb
Maximum chassis inclination
4 ° sideways up to 5.5m +0.6m/-0.3m
2 ° sideways above 5.5m
4 ° fore & aft
Maximum manual force 400N
