Appendix C – Inspection Checklists
S2255RT S2755RT - 15286-1
Frequent Inspection and Maintenance – Every 90 Days or 150 Hours
Overload system test
CE machines only
Battery disconnect switch
Upper Controls
Operating controls
Parking brakes
Emergency stop
Lowering alarm–if equipped
Drive motion alarm
–if equipped
Electrical power outlet
Travel speed
Horn
Battery condition indicator
Options
Flashing light
Rough Terrain Scissor Interlock
Test
Check the lift function at 120% maxi-
mum load capacity. Start the test with
the platform fully lowered. Verify that
the lift function cuts out automatically,
the alarm sounds and the red light
on the control panel fl ashes before
the platform reaches an elevation of
approximately 1.8 m (6′).
Shuts off all controls
Check for smooth operation and
proper speed
Proper operation
Shuts off power to upper controls
Verify that alarm sounds while the
platform is lowering
Verify that alarm sounds while chassis
is in motion
Check for proper operation of outlet
and GFCI
Verify proper travel speed
Low speed
0.4 mph (0.64 km/h)
High speed
3.3 mph (5.2 km/h)
Check for proper operation
Check for proper operation
Check for proper operation
All Snorkel scissor lifts in the Snorkel
‘SRT, SR and S/RT Series are fi tted
with a very important safety feature,
a ‘Stabiliser/axle/scissor Interlock’
system that prevents the stabilisers
being moved while the platform is
elevated, and prevents the platform
being raised if the rear axle is oscil-
lated and the stabilisers are not set
or the machine is tilted.
The correct operation of the Stabi-
liser/scissor Interlock is critical to
ensure that the Scissor is operated
safely and with minimum risk.
DANGER
To ensure the interlock system is
functioning correctly before op-
erating the scissor the following
test must be carried out prior to
operation each day, in conjunction
with all other relevant daily pre-op-
erational checks:
Stabiliser locked out when plat-
form is elevated test the stowed
position. (Continued on to next
page)
120% Maximum Load
S2255RT 420kg (925lbs)
S2755RT 300kg (660lbs)
Item Procedure Information P/F/R
To Next Page
