Chapter 2 – Specifications
S2646E/S3246E – 0410051 5
General Specifications S3246E
Aerial Platform
Working height 38′ (11.58 m)
Maximum platform height 32′ (9.75 m)
Turning radius
Inside 10″ (25.4 cm)
Outside 101″ (2.5 m)
Wheelbase 75″ (1.9 m)
Ground clearance
Pothole protector raised 4″ (10.1 cm)
Pothole protector lowered 1″ (2.5 cm)
Maximum wheel load 2,928 lbs (1328 kg)
Maximum ground pressure 196 psi (13.8 kg/cm²)
Weight, GVW
Approximate 6,620 lbs (3003 kg)
Stowed width 46″ (116.8 cm)
Stowed length 96″ (243.8 cm)
Stowed height
Guardrails raised 94″ (238.7 cm)
Guardrails lowered 67″ (170.1 cm)
Platform
Dimensions
Main 45″ x 94″ (114.3 cm x 238.7 cm)
Extension 41″ x 36″ (104.1 cm x 91.4 cm)
Total length with extension 130″ (330.2 cm)
Rated work load
Total 700 lb (317.5 kg)
Extension 250 lb (113.3 kg)
Maximum number of occupants
Outside 1 person
Inside 2 people
AC outlet 120 V, 15 amp
Function Speed
Platform raise 40 to 50 seconds
Platform lower 50 to 60 seconds
High drive
Platform lower than 7 to 8 feet (2.1 to 2.4 m)
0 to 2 mph (3.2 km/h)
Low drive
Platform higher than 7 to 8 feet (2.1 to 2.4 m)
0 to 0.5 mph (0.8 km/h)
Drive System
Standard Two wheel drive
Gradeability 25%
Maximum drive height 32′ (9.75 m)
Drive/Lift Level Sensor Interlock
Side-to-side 2 degrees
Front-to-rear 4 degrees
Tires
Nonmarking solid rubber 16″ x 5″ (40.6 cm x 12.7 cm)
Electrical System
Voltage 24 V DC negative chassis ground
Source Four - 6 V 240 amp hour batteries
Fluid recommended distilled water
Charger 25 amp
Hydraulic System
Maximum pressure 3,100 psi (21,373.75 kPa)
Reservoir capacity 9 US gal (34 l)
System capacity 9.25 US gal (35 l)
Maximum operating temperature 160°F (71°C)
Hydraulic fluid recommended
Above 10°F (-13°C) Mobil DTE-13M (ISO VG32)
Below 10°F (-13°C) Mobil DTE-11M (ISO VG15)
Ambient Air Temperature Operating Range
Fahrenheit 0°F to 110°F
Celsius -18°C to 43°C
