page 3 - 2 Rev A S3970RT, S3370RT & S2770RT – 13865-1
3. Specifications
SPECIFICATIONS S3370RT
Nominal working height
12.12m 39' 2”
Roll out deck size
1200mm 48”
Drive speed (below 2.4m)
0 to 4.5kph 0 to 2.8mph
Drive speed (above 2.4m)
0 to 0.35kph 0 to 0.22mph
Safe working load - Main deck
(Roll out deck not extended)
450kg 990lbs
Safe working load - Main deck
Safe working load - Roll out deck extended
330kg
120kg
726lbs
264lbs
Platform size
2.73 x 1.65m 8’ 11” x 5’ 5”
Stowed height
2.7m 8' 10"
Stowed height (hand rails folded down)
2.0m 6' 6"
Overall length
3.36m 11’ 0”
Overall width
1.77m 5' 9"
Gradeability
35%
Lift time
50 seconds
Turning radius (inner)
2.38m 7’ 8”
Turning radius (outer)
4.75m 15’ 6”
Maximum wind speed (12.5m/s)
45km/h 28mph
Insulation rating
Nil
Tyres - Poly filled loader lug
27" x 10.5" x 15"
Overall weight
3620kg 7964lbs
Ground clearance
350mm 13.8”
Maximum sound level at platform
86db
Stabiliser maximum load
2075kg 4574lb
Maximum chassis inclination
2.5
O
/4
O
Allowable manual force
400N
n
General Specifications, Standard Machine S3370RT
