Snorkel S3970RT - Placards and Decals; Standard Placards and Decals

page 7 - 12 Rev A S3970RT, S3370RT & S2770RT – 13865-1
7. Daily Inspection and Maintenance
No Part No Description Req
1 1843
Decal - Warning, N.Z. only
1
9428
Decal - Electrical hazard,
Australia only
1
2 9208
Decal - Water
1
3 96924-9
Decal - Warning stripes
yellow/black
4m
4 12833-8
Decal - Serial number
1
5 9751
Decal - N.Z. made
1
6 13471-10
Decal - S3970RT
2
511081-000
Decal - S3370RT
2
511079-000
Decal - S2770RT
2
7 12699-4
Decal - Rated load, S3970RT
1
12699
Decal - Rated load, S3370RT
1
11346-1
Decal - Rated load, S2770RT
1
8 0073298
Decal - Foam tyres
1
9 451986
Decal - Interlocks
2
10 476706
Decal - Explosive fumes
2
11 12574
Decal - Danger with alarm
1
12 511101-000
Decal - Snorkel logo
5
13 560240
Decal - Lower control box
1
14 12689
Decal - Upper control box
1
15 560272
Decal - Emergency stop upper
box
1
16 605726
Decal - Diesel fuel
1
17 12753
Decal - Emergency bleed
down
1
18 12814
Decal - Hydraulic fluid
1
19 58365-6
Decal - Safety prop
1
20 96924-9
Decal - Warning stripes
yellow/black
21 300699
Decal - Operators checklist
1
No Part No Description Req
22 0323897
Decal - Must not operate
1
23 621486
Decal - Forklift
4
24 302950
Decal - Hydraulic oil level
1
25 300700
Decal - Shearing hazard
1
26 13370
Rev B
Decal - Emergency operation,
emergency lowering &
emergency pushing
1
27 0083427
Decal - Lifting/tie down
4
28 12815-4
Decal - Hydraulic circuit,
S3970RT / S3370RT /
S2770RT
1
29 12815-2
Decal - Electrical circuit,
S3970RT / S3370RT /
S2770RT
1
30 562426
Decal - Operators manual
enclosed
1
31 0372061
Decal - Torque wheel nuts
4
32 511067-000
Decal - www.snorkellift.com
2
33 501453-000
Decal - Foot crush hazard
4
n
Placards and Decals
Look to see that all plac ards and de cals are in place and leg i ble. Re place any miss ing or il leg i ble plac ards
or de cals be fore plac ing the S3970RT / S3370RT / S2770RT into ser vice for the daily work shift.
De cal and plac ard kits for the S3970RT / S3370RT / S2770RT are avail able from Snor kel deal ers.
q Standard placards and decals
l
See page 7 - 11 for the following items:
