q Bubble Level
Figure 4.7 - Bubble Level
A bub ble level is lo cated on the plat form side rail,
be low the plat form con trol box. Watch the bub ble
level while you set the sta bi lis ers man u ally. Lower
the sta bi lis ers, one at a time, just enough to set the
bub ble be tween the guide lines in both the fore and
aft and lat eral gauges. When the bub bles are cen -
tered the plat form is level and can safely be raised.
page 4 - 2 Rev A S3970RT, S3370RT & S2770RT – 13865-1
4. Gauges
