If there is visible space around
the hose when placed in the
hose slot, you may be using a
12 mm hose and require the
Hose Sleeve be installed.
The Hose Sleeve is required if you use a 12 mm hose.
It is not compatible with 15 mm or larger diameter hoses.
An extra sleeve is included in the event of sleeve breakage.
You will only use one Hose Sleeve at a time.
2 to 3 inches
Position the Hose Sleeve
2 to 3 inches from the
connector.
Line up the Hose Sleeve
with the gasket, place
it in the Hose Slot and
shut the lid.
Position the hose on the
Nub side of the Hose
Sleeve. Slide the hose
until the Sleeve “clicks”
into place between two
of the hose ribs and
close the Sleeve.
A
C
B
The images below are actual size and can be used to determine
which hose you have.
USING THE HOSE SLEEVE
[OPTIONAL]
The SoClean requires a snug fit around the hose when placed into
the hose slot and the lid is closed. If there is space around the
hose and this is not achieved, the SoClean will not operate.
2
19 mm
Hose
15 mm
Hose
12 mm
Hose
32
