ySController A15 - 549779A - SOCOMEC
8. INST
ALLA
TION
8.1. Pr
oduct dimensions
dimensions in mm.
5
93
96
8.2. Mounting
8.2.1. Door mounting
Door cut-out of 93(+0.8) x138(+1) mm, door thickness 1.5- 3mm.
Remove all
connectors and
clip befor
e inserting
the contr
oller in
the cut-out
then x
the contr
oller in
place using
all 4
xations clips
(cf. image below):
138
(0/+1)
93
(0/+0,8)
1,5 - 3
12
14
