Pr ogramming the ATyS p
1
SETUP
2
VOLT. LEVELS
3
FREQ. LEVELS
4
PWR. LEVELS
5
TIMERS VALUE
6
I-O
7
COMM
8
DATE/TIME
NETWORK 4NBL OV. U I 115% OV. F I 105% OV.P I 0000 kVA 1FT 0003 SEC IN 1 --- NO DHCP NO (9) YEAR
AUTOCONF NO (7) OV. U HYS I 110% OV. F HYS I 103% OV.P HYS I 0000 kVA 1RT 0180 SEC IN 2 --- NO IP 1-2 192.168.
(9)
MONTH
NEUTRAL AUTO UND. U I 085% UND. F I 095% OV.P I I 0000 kVA 2FT 0003 SEC IN 3 --- NO IP 3-4 .002.001 DAY
ROT PH. --- UND. U HYS I 095% UND. F HYSI 097% OV.P HYS I I 0000 kVA 2RT 0005 SEC (2) IN 4 --- NO GAT1-2 000.000.
(9)
HOUR
NOM. VOLT 400 V UNB. U I 00% OV. F I I 105% 2AT 0005 SEC (1) IN 5 --- NO GAT3-4 .000.000 MINUTE
NOM. FREQ 50 Hz UNB. U HYS I 00% OV. F HYS I I 103% 2CT 0180 SEC (1) IN 6 --- NO MSK1-2 255.255.
(9)
SECOND
APP M-G OV. U I I 115% UND. F I I 095% 2ST 0030 SEC (1) IN 7 --- NO (8) MSK3-4 .255.000
PRIO TON NO (1) OV. U HYS I I 110% UND. F HYS I I 097% ODT 0003 SEC IN 8 --- NO (8) ADDRESS 005
PRIO EON NO (3) UND. U I I 085% TOT UNL (1) IN 9 --- NO (8) BDRATE 9600
PRIO NET 1 (2) UND. U HYS I I 095% TOT 0010 SEC (1) IN10 --- NO (8) STOP BIT 1
RETRANS NO UNB. U I I 00% T3T 0000 SEC (1) IN11 --- NO (8) PARITY NONE
CT PRI 100 UNB. U HYS I I 00% TFT UNL (1)
IN12 --- NO (8)
CT SEC 5 TFT 0600 SEC (1) IN13 --- NO (8)
S1=SW2 NO E1T 0005 SEC (3) IN14 --- NO (8)
BACKLGHT INT E2T UNL (3) OUT 1 POP NO
CODE P 1000 E2T 0010 SEC (3) OUT 2 --- NO (8)
CODE E 0000 E3T 0005 SEC (3) OUT 3 --- NO (8)
BACKUP SAVE E5T 0005 SEC (4) OUT 4 --- NO (8)
E6T LIM (4) OUT 5 --- NO (8)
E6T 0600 SEC (4) OUT 6 --- NO (8)
E7T 0005 SEC (4) OUT 7 --- NO (8)
LST 0004 SEC (5) OUT 8 --- NO (8)
EET 0168 H (6) OUT 9 --- NO (8)
EDT 1800 SEC (6)
(1) When «APP» is set to «M-G»
(2) When «APP» is set to «M-M»
(3) When one of the I/P is set to «EON»
(4) When one of the I/P is set to «EOF»
(5) When one of the O/P is set to «LSC»
(6) When one of the O/P is set to «EES»
(7) If the product is in manual mode
(8) With optional I/O modules
(9) With Ethernet module
The ATyS p is to be programmed powered up and after wiring
the ATS Controller using the keypad or with the user-friendly Easy
(Downloadable free from www.socomec.com).
The ATyS p is delivered with default setting values based on
most used customer application requirements. The minimum
of network and application together with the voltage and frequency
Hz, Phase rotation and Neutral Position quick and easy.
A - Programming with Easy Config Software
the setting boxes from left to right until all desired settings in each
window have been completed. Help pop ups are included to show
the minimum and maximum setting values allowed. The software
includes most SOCOMEC products so before programming click
NEW and select the product “ATyS p” from the list of products
available.
When the ATyS p is powered and communicating, the software will
include a screen to monitor and display the ATyS p status.
Control through software (such as changing switch position I-O-II) is
also possible when in Super User Mode.
Enter code (factory code = 1000) using navigation push buttons (14).
Press and hold for 5 s “Validation” push button (17).
Note 1: !"#$%#!&'(
Note 2:)$*'+,"$-.%1"1""$1%
11"$%&!'"$%""2%$"(
B - Programming with the ATyS p keypad
STEP 6
Check
Whilst in manual mode, check the
wiring and if ok power up the
product.
LED “Power” Green: ON
LED Manuel/Fault Red: ON
STEP 5
Power 208-277V~
Power 208-277V~
+/-20%
+/-20%
Optional Modules
Communication between the software and the ATyS p may be done through the Ethernet/Modbus TCP or Modbus RTU modules
that are available as an option. The ETHERNET / MODBUS modules are to be installed in one of the slots provided in the ATYS p
ATS control unit.
ETHERNET or MODBUS modules as well as isolated from
the product and simply saved on a PC for download at any
convenient time.
Note:33&. & 11 " "' 4 " 7 8
9""''$%"$"%$!
$"%$! "( : 1% ;9*<=.
"3&.11""'789",
1%)3>)?+)3"""'789"(
?'$"3&.11"$&1"'"$(
(Volts, Hz, Neutral pos., Ph rotation)
Press 5s
Go To
1
SETUP
Scroll to
AUTOCONF
Enter code 1000
Set to
YES
Press 60 ms
Save : press 5s
Note:."$1
I
"$"$1
II
!
#!"!&""2%$"(
ATyS p devices may also be programmed through the ATS controller keypad.
This programming method is necessary for products not equipped with Ethernet
or Modbus communication modules that facilitate programming through
programming method most especially when changing a few parameters or
simply interrogating the product.
Press and hold for 5 s “Validation” push button (17).
Access through the keypad is possible in Automatic or Manual mode, when the
product is in a stable position (I, 0 or II) with at least one supply source available.
Programming is not accessible whilst any cycle sequence is running.
1
32
N
1
3
2
1
2
3
1
3
1
N
17
14
3)$"1!:!.$#$'"$
;""$%@)%)$1$"$"@)#(((
Extended I/O
2xIP 2xO/P
Modbus
RS485
Pulsed O/P 4-20mA
Ethernet/Modbus
TCP Simple
To Next Page
