10 EN
COUNTIS E21/E22 - 545875B - SOCOMEC
6. CONNECTION
6.1. Connecting the COUNTIS E21/E22
SET
N
A
A-V
A
A-V
A
A-V
L1
L2
L3
1 2 3 4 5 6
Fixed / exible
0.14 mm
2
->
2.5mm
2
0.27" / 6.9 mm
PZ2
4.5 lb.in /
0.5 Nm max.
Fixed / exible
1.5 mm
2
->
35mm
2
0.47" / 12 mm
PZ2
17.70 lb.in /
2 Nm max.
