9. USE
Switch menus by pressing " ". Press " " to see the electrical readings or information within a menu.
The menus and related measurements are described in the table below:
Tariff 1
(Tar.1)
Tariff 2
(Tar.2)
Total (tot) Partial read-
ings and en-
ergy balance
(Par.b)
Realtime
values
(rt)
Information
(inFo)
Tariff 1 - Imported
and exported
active energy
Tariff 2 - Imported
and exported
active energy
Total imported
and exported
active energy
Partial imported
active energy by
tariff
Active, apparent
and reactive
power
Metrological
firmware version
______________ ______________ ______________ ______________ ______________ ______________
Tariff 1 - Imported
and exported
inductive reactive
energy
Tariff 2 - Imported
and exported
inductive reactive
energy
Total apparent
energy
Partial imported
active energy
Phase/phase and
phase/neutral
voltage
Non-metrological
rmware version
______________ ______________ ______________ ______________ ______________ ______________
Tariff 1 - Imported
and exported
capacitive
reactive energy
Tariff 2 - Imported
and exported
capacitive
reactive energy
Total imported
and exported
inductive reactive
energy
Partial exported
active energy by
tariff
Three-phase
current
Checksum of
metrological
firmware
______________ ______________ ______________ ______________ ______________ ______________
Tariff 1 - Imported
and exported
reactive energy
Tariff 2 - Imported
and exported
reactive energy
Total imported
and exported
capacitive reactive
energy
Partial exported
active energy
Power factor
Checksum of
non-metrological
rmware
______________ ______________ ______________ ______________ ______________ ______________
Go back to rst
screen, menu
"Tar.1"
Go back to rst
screen, menu
"Tar.2"
Total imported
and exported
reactive energy
Partial apparent
energy
Frequency Connection type
______________ ______________ ______________ ______________
Go back to rst
screen, menu
"tot"
Partial imported
and exported
reactive energy
Go back to rst
screen, menu "rt"
Go back to rst
screen, menu
"info"
______________
Active energy bal-
ance
______________
Reactive energy
balance
______________
Go back to rst
screen, menu
"Par.b"
