socomec COUNTIS E21 User Manual

26 EN
COUNTIS E21/E22 - 545875B - SOCOMEC
TARIFF for Ea+
Tariff management Yes (via input)
Number of tariffs managed 2
Tariff input Yes
Input type Opto-isolated
Voltage
0V --> Tariff 1
80-276VAC-DC --> Tariff 2
METROLOGICAL LED (Ea+, Ea-)
Pulse value 1000 pulses / kWh
Colour Red
PULSE OUTPUT
Type Opto-isolated - 250 VAC/DC 100mA according to EN 62053-31
Pulse weight 100 Wh
O1
O2
Ea+
Er+
DISPLAY
Type 8-digit LCD with backlight
Refresh time 1s
Backlight activation time 10s
Active energy: 1 display, 8-digit 000000.01 - 999999.99 kWh
Reactive energy: 1 display, 8-digit 000000.01 - 999999.99 kvarh
Apparent energy: 1 display, 8-digit 000000.01 - 999999.99 kVAh
Realtime active power: 1 display, 4-digit 00.00 - 99.99 kW
Realtime reactive power: 1 display, 4-digit 00.00 - 99.99 kvar
Realtime reactive power: 1 display, 4-digit 00.00 ... 99.99 kVA
Realtimevoltage: 1 display, 4-digit 000.0 ... 999.9 V
Realtime current: 1 display, 4-digit 00.00 ... 99.99 A
Power factor: 1 display, 4-digit 0.001-1.000
Frequency: 1 display, 4-digit 45.00-65.00 Hz
SAVING
Energy registers In FRAM memory
ENVIRONMENTAL CONDITIONS
Mechanical environment M1
Electromagnetic environment E2
Operating temperature range -25°C to +55°C
Storage temperature -25°C to 75°C
Humidity ≤80%
Installation Internal (box/cabinet)
Vibrations ±0.075 mm
HOUSING
Dimensions W x H x D (mm) Modular - width of 4 modules (DIN43880) 72x90x64
Mounting On DIN rail (EN 60715)
Connection capacity, tightening torque See chapter "6. Connection", page 10
Protection index Front: IP51 - casing: IP20
Insulation class Class II (EN 50470-1)
Weight 440 g
