COUNTIS E45/E46 - 547983A - SOCOMEC
9. CONFIGURATION
The device can be con gured directly from the COUNTIS E45/E46 screen in programming mode or via the communication link.
The paragraphs below describe con guring using the screen.
9.1. Onscreen conguration
From the screen, go to programming mode to change your communication settings. How to browse through the
programming mode is described in the following stages:
FUNCTION WHERE BUTTONS PRESS
Switch menus
Every page with the
exception of SETUP 1/2
Realtime
Switch pages within a menu Every page within a menu
Realtime
Go to menu SETUP 2 Menu page SETUP
>3 sec
Go to menu SETUP 1
Every page with the
exception of SETUP 1
SET >3 sec
Change a value/digit Pages SETUP 1/2
Realtime
Confirm a value/digit Pages SETUP 1/2
Realtime
Exit menu SETUP 1/2 Menu SETUP 1/2
>3 sec
Start/stop the displayed partial meter Partial meter menu
+
Realtime
Reset the displayed partial meter to zero Partial meter menu
+
>3 sec
Display test
Every page with the
exception of SETUP 1/2
+
>10 sec
