COUNTIS E45/E46 - 547983A - SOCOMEC
4.6. Electrical values measured
4.6.1. Measurements
Settings vary by model.
Realtime values Symbol
Measurement
Unit
LCD display
Via
communication
Phase to neutral voltage
∑V
V

V1, V2, V3

Phase to phase voltage
∑U

U12, U23, U31

Current
∑I
A

I1, I2, I3

Power factor
∑PF
 
PF1, PF2, PF3

Apparent power ∑S, S1, S2, S3 kVA
 
Active power ∑P, P1, P2, P3 kW
 
Reactive power ∑Q, Q1, Q2, Q3 kVAr
 
Frequency f Hz

Phase sequence CW / CCW

Power direction

Logged data
Total active and reactive energy
Ea, Er (∑)
kWh, kvarh
 
Ea, Er (by phase)

Total apparent energy Eap (∑) kVAh

Total inductive and capacitive reactive
energy
Er (∑) kvarh

Total active, reactive energy for each tariff
(T1/T2/T3/T4)
Ea, Er (∑) kWh, kvarh
 
Total reactive, inductive and capacitive
energy for each tariff (T1/T2/T3/T4)
Er (∑) kvarh

Active, partial energy for each tariff
(T1/T2/T3/T4)
Ea (∑) kWh

Active, reactive and apparent partial energy
Ea, Er kWh, kvarh
 
Eap (∑) kVAh

Energy balance ∑ kWh, kvarh

Miscellaneous
Present tariff T 1/2/3/4
 
Partial counters BY START/STOP

Pulse output status
Active/Not
active

NOTE: ∑ is the sum of the meter readings for each phase, divided by 3.
NOTE: If you have a 3-wire connection the following voltage readings are not available; phase-neutral, neutral current, phase
power, power factor for each phase and power for each phase.
