4.4.1. TE solid-core current sensors
plate.
4.4.1.1. Range
TE-18 TE-18 TE-25 TE-35 TE-45 TE-55
Pitch
25mm 35mm 45mm 55mm
I nominal
Maximum l
Reference
4.4.1.2. Dimensions
L
P
W
H
L
W
P
T
H
Dimensions in/mm
TE-18 TE-25 TE-35 TE-45 TE-55
Pitch
0.71
0.98
25
1.37
35
1.77
45
2.16
55
LxHxD
1.10 x 0.79 x 1.77
0.98 x 1.28 x 2.56
1.37 x 1.28 x 2.79
1.77 x 1.28 x 3.38
2.16 x 1.28 x 3.93
Window (W)
ø 0.33
0.53 x 0.53
0.82 x 0.82
1.22 x 1.22
1.61 x 1.61
(T)
- 0.69
17.5
0.69
17.5
0.77
0.85
21.5
