31
EN

7. CONNECTING THE OPTIONAL MODULES
7.1. Description of the terminals
7.1.1. Input/output modules
7 mm
0.14 mm
2
-> 1.5 mm
2
solid
0.14 mm
2
-> 1.5 mm
2
stranded

7 mm
0.14 mm
2
-> 1.5 mm
2
solid

2
-> 1.5 mm
2
stranded
4 positions

d
Supply

7 mm
0.14 mm
2
-> 1.5 mm
2
solid
0.14 mm
2
-> 1.5 mm
2
stranded

10 mm
0.2 mm
2
-> 2.5 mm
2
solid

2
-> 1.5 mm
2


DIRIS O-iod
Module 2 digital
inputs/outputs

DIRIS O-ioa
Module 2 analogue
inputs/outputs

DIRIS O-it
Module 3
temperature inputs

7 mm
0.14 mm
2
-> 1.5 mm
2
solid 0.14
mm
2
-> 1.5 mm
2
stranded

7 mm
0.14 mm
2
-> 1.5 mm
2
solid

2
-> 1.5 mm
2
stranded

PT100 or PT1000
